Home Products
MEYER
WALL LIGHT
OUTDOOR LIGHTING
8 781 146 009

Housing made of corrosion‑resistant die‑cast aluminum AlSi12, polyester powder coated by high‑quality and UV‑stabilized coating process, Colour: black ral 7021, all exterior parts are stainless steel, tempered safety glass, anti‑reflective coating from 1 side, with partial frosting for uniform light diffraction and dark silk‑print, silicon gasket, closure with 4 stainless steel screws, wall bracket: 2 drilled holes Ø 7 mm, spacing 35 mm, tilt range: 180°, cable gland: M20, connecting terminal: 3 pole, highly efficient optics made of transparent thermoplastic for precise lighting tasks , integral driver (AC/DC), CRI > 80, max 3 SDCM, service life L80/B20 > 50.000 h, Beam angle (fwhm): 32° / 128°, luminous flux: 1521 lm, wattage: 28 W, delivered lumens 54 lm/W, protection type IP65, protection class I, impact resistance IK08, windage area 0,032 m², dimensions (L×H×W): 472 × 50 × 62 mm, weight 2.1 kg. The modular luminaire design makes the replacement of components possible. The product meets the demands of the applicable EU guidelines and product safety regulations and bears the CE mark.

Compare
LINEALIGHT
WALLWASHER
OUTDOOR LIGHTING
81690W90
Single emission lines for outdoor application. The warm white LED light source with a extra wide flood light distribution is composed of 18 powerled LEDs. The device body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP68; the total weight is of 2.500 kg. The power supply cable is included and features a 0.250 m length. The device features protection class II and can be floor-mounted with an outer casing, code 99765 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.
Compare
UNIOS
RECESSED DOWNLIGHT
OUTDOOR LIGHTING
ION RL_IONR0180.WB30.MH-CC090002

Available in 4 sizes, an extensive range of accessories and 15,000+ customisations, the ION R Downlight is an outstanding contender for all lighting needs. With 2 models, Standard and Wallwasher, the ION R Downlight can be specified for both horizontal and vertical lighting needs.

Compare
LUMASCAPE
FLOODLIGHT
OUTDOOR LIGHTING
QUADRALUX_Q2_LS9120_30D
A small architectural grade spotlight that combines technology and performance in a modern form factor. Packed with features including EasyGlow™ visual comfort, and CoolDrive™ thermal management technologies. Unique and flexible mounting with glare control accessories enable installation in multiple orientations. Supplied standard with designer optics, providing superb color-over-angle consistency. Available with integrated Dali control, 0-10 V dimming or as non-dimmable. DIMENSION: 235(L)*68(W)*228(H)mm.
Compare
TRAXON
WALLWASHER
OUTDOOR LIGHTING
WA.GC.233111100

The Traxon Washer Go Cube is a DC line powered exterior luminaire used to distinguish facades, walls, and architectural landmarks with a even colour wash effect. Washer Go Cube compact design features efficient electrical and optical system, making it ideal for budget-conscious projects.

Compare
LED LINEAR
INGROUND LINEAR LIGHT
OUTDOOR LIGHTING
VARIOLED OCEANOS WHITE HIGH CRI HD6

Robust in ground grazer made of V4A stainless steel available in standard lengths and 10° and 30° beam optic. Oceanos has an environmental resistance of IP67. This is made to the unique polyurethane encapsulation. Different optics enable adaptability to different projects. The 10° optic suit well for wall grazing, as the 30° and opal are suitable for accent lighting. Oceanos has an IK10 classification hence is very robust. The ability to withstand a pressure of 30kN is equivalent to being traversed by a vehicle according to DINEN605982.

Compare
XAL
SUSPENDED PENDANT LIGHT
INDOOR LIGHTING
BETO CIRCLE 800 DIRECT-INDIRECT_074-7443038R

Ring-shaped light fitting in rolled and seamlessly welded extruded aluminium profile; extremely slim design (only 42 x 42 mm); surface jet black powder coated; suspended luminaire with 1500mm cable suspension (canopy central); with integrated toolless suspension height adjustment on the luminaire; incl. transparent feed; extruded profile for improved thermal management;

Compare
IGUZZINI
SPOTLIGHT
INDOOR LIGHTING
ROBIN_QV50
Miniaturised adjustable spotlight with adapter for installation on 48V low voltage track. Made of die-cast aluminium with passive dissipation system. The adapter made of a thermoplastic material includes the DC/DC driver circuit with a DALI power line dimmable function. Integrated «power line» technology allows each spotlight on the track to be adjusted separately. The swivel joints allow the spotlight to be rotated by 360° and tilted by 160° with the option of installing the spotlight on a 48V track in both an "up" and "down” position. The set back position of the optic unit guarantees a high level of visual comfort. A high definition thermoplastic lens with the option of using additional accessories to create other light effects.
Compare
COLORS
UNDERWATER LIGHT
OUTDOOR LIGHTING
CLEAR AQUAGLO F22

Aquaglo F22 series, the IP68 rated flexible LED neon (with maximum 5m. depth up to 30m. running length), gives you unprecedented freedom in lighting design for indoor and outdoor underwater applications, featured with continuous glow, multiple color options, custom length, and two bending directions. As a professional underwater luminaire, it is UL 676 certified and resistant to rust, chlorine, UV proven by extensive tests, aiming to create the safe and cozy ambient out of your expectation. Dimension 17 mm x 16 mm x 1000 mm.

Compare
FLOS
RECESSED DOWNLIGHT
INDOOR LIGHTING
EASY KAP Ø30 FIXED_05.7626.B1


Compare
NEKO
ADJUSTABLE DOWNLIGHT
INDOOR LIGHTING
TA8+ M4P6-9TW3813D-NN


Compare
LUMASCAPE
WALL LIGHT
OUTDOOR LIGHTING
LS201LED - 6H6 WD

The LS201LED Hakea is a compact, fixed position, direct or indirect accent used for grazing walls or other accent illumination tasks. The luminaire is constructed from either copper or powder-coated aluminIum, providing a variety of aesthetic options. This luminaire is ideal for use in modern architectural designs, and features the Lumascape d5 driver technology for advanced dimming and control options.

Compare
SPARK
RECESSED DOWNLIGHT
INDOOR LIGHTING
SPK2611-20W-45D

Recessed fixed square downlight, luminaire body made of aluminium housing with white powder coated trim finish. Reflector come with Chrome black, White and Silver finish. Honeycomb accessory available upon request.

Compare
SIMES
WALL LIGHT
OUTDOOR LIGHTING
S.8000W.01
Decorative elements and reflector in solid bronze are treated with a transparent protective layer that maintains the color and ensures quality and durability. Die-cast EN AB-47100 aluminium housing with high corrosion resistance. Stone wash surface treatment prior to painting process. A4 grade Stainless Steel screws with 2,5-3% molybdenum content which increases the resistance against corrosion. Silicone gaskets. Painting Process : 3 Step Process 1) Surface treatment with BONDERITE. A heavy metal free chemical surface treatment containing ceramic nano particles giving a cohesive, inorganic and highly dense protective coating. 2) PRE POLYMERIZATION a process of introducing an epoxy primer with excellent characteristics to the paint which also offers very high resistance to oxidation due to its Zinc content. 3) POLYMERIZATION a process with the application of polyester powder with high resistance against UV rays and harsh weather conditions. Resistance test protection for Marine applications for 1200h. Mechanical resistance IK 06. This luminaire contains built-in LED modules. In case of damage or malfunction please contact the manufacturer to receive additional instructions on how to replace and relative spare parts to order. The LED modules cannot be handled in the luminaire by the end user. This product contains a light source of energy efficiency class: E. LED modules are engineered accordingly to the existing regulations of Lumen Maintenance (LM80) and Technical Memorandum (TM21), where uniformity and quality of the light is 70,000 hours referred to L80 B10 Ta 25 ° C (50,000 hours referable to L80 B10 Ta 40°C). Lifespan of the luminaire min. 50,000 hours at 40°C. Performance Ambient temperature Tq 25°C. Operating ambient temperature range is from -20°C to +50°C. Storage temperature range from -20°C to +60°C.
Compare
TRAXON
LINEAR LIGHT
OUTDOOR LIGHTING
Allegro Linear 2.1 AC RGBW 60x30

The Allegro Linear 2.1 AC RGBW family is a slim-profile, AC-line powered high-brightness luminaire. The family is controllable via DMX512, and is available in four lengths, from 320mm to 1215mm with 16.7 million additive RGB colors plus white, and various optics. The simplicity of the luminaire’s topology means it can be easily daisy-chained to form long runs. Remote Device Management (RDM) circuits are built into each luminaire that enables extensive control and monitoring of the entire lightin

Compare
